TEMP20 FIRERATED FOR 20 MINUTE FIRE DOORS
Temp20
Product Detail
STANDARDS
Classified and labeled by QAI Laboratories. All fire tests performed in accordance with UL 10C (positive pressure, without hose stream) NFPA 252, NFPA 80
LABELING
Each GLASSOPOLIS TEMP20™ fire glass lite must be permanently labeled with product name, manufacturer, QAI mark, and fire rating as per code
INSTALLATION
Install GLASSOPOLIS TEMP20™ in matching fire-rated doors, following QAI guidelines and supplier instructions
Features
- Fire-rated to 20 minutes
- Available in large sizes for big doors
- Impact-safety rated to ANSI Z97.1 and CPSC 16 CFR1201 (Cat I and II)
- Transparent and wireless
- Tempered glass for safety and security
- Direct supply for door manufacturers
- Can be used in standard fire-rated doors of same rating
- Available in an insulated glass unit (IGU)
- Meets NFPA 80 requirements for certification and labeling
- Certified by QAI Laboratories
- Thickness: ¼” (6 mm)
- Weight: 3 lbs/ft
Listings
| Product | Rating | Application | Max Sq In (in 2 | Max Width (in) | Max Height (in) | Stop Height (in) |
|---|---|---|---|---|---|---|
| Temp20 | 20mn | Doors | 3204 | 36 | 89 | 1/2 |
Resources
GLASSOPOLIS TEMP20™ is a ¼” (6 mm) thick, clear glass, fire-rated for 20-minute fire doors and impact-safety rated. Ideal for doors, sidelites, and more, it offers transparency, safety, and is certified by QAI Laboratories.
