PYRAN® PLATINUM GLASS CERAMIC

PYRAN® PLATINUM GLASS CERAMIC

PYRAN ® PLATINUM is an award winning fire-rated glazing with market leading technology. It is made in Germany by SCHOTT using a next generation float process that produces a very high quality glass-ceramic with the largest sizes in the industry. It compares very favorably to traditional products like FireLite ® that may require corrective grinding and polishing. Where other glass-ceramics can be yellow-brown in color, Platinum has a hint of grey/green like regular glass. And Glassopolis has great pricing on PYRAN ® Platinum. In terms of optical quality, color and price, you can’t beat PYRAN ® Platinum from Glassopolis.

Product Detail

PLATINUM

Thickness: 3/16” (5mm). Weight: 2.6 lbs/ft
2

PLATINUM F

Impact/Safety Rated to ANSI Z97.1 and CPSC 16CFR1201 CAT II
Thickness: 3/16” (5mm). Weight: 2.6 lbs/ft

PLATINUM L

Impact/Safety Rated to ANSI Z97.1 and CPSC 16CFR1201 CAT II
Thickness: 3/8” (9mm). Weight: 4.3 lbs/ft
2. STC rating: ~36dB

Features

  • Fire-rated up to 90 minutes (180 minutes in doors) with required hose stream test
  • Premium glass-ceramic
  • Surface finish: near optical quality with true color rendition
  • Environmentally friendly – produced without the use of toxins
  • Suited for use with standard fire-rated frames with the same rating
  • Can be used in insulating units
  • Largest sheet size in the industry: 51″ x 99”. Call for current availability

Listings


Product Rating Application Max Sq In (in 2 Max Width (in) Max Height (in) Stop Height (in)
Platinum and Platinum F Up to 90 min
Up to 90 min
Other than doors
Doors (non-temp rise
4933
3708
98-1/4
37-3/4
98-1/4
98-1/4
5/8
5/8
Platinum L Up to 90 min
Up to 90 min
Other than doors
Doors (non-temp rise
3143
2736
99
37-3/4
99
99
5/8
5/8
Platinum, F, L 180min Doors 100 12 32 1/2

Resources

Classified and labeled by Underwriters Laboratories, Inc. for the United States and Canada with File-No. R25738. All fire tests performed in accordance with UL 9, UL 10C, UBC 7-2 (1997), UBC 7-4 (1997), NFPA 252, NFPA 257, NFPA 80, ASTM E2010-01, ASTM E2074-00, CAN/ULC-S104, and CAN/ULC-S106. All listing information is subject to change. Note: This product is not considered a barrier to radiant heat and has not met the ASTM E-119 or UL 263 test standards.
